COIL POLISHINGTHIN PLATE BELT SANDER BS-610-2H

CHARACTERISTIC

  • Using stainless steel for keeping from rusting
  • Adjusting 1µ/unit a gap between belt and plate surface (Auto/Manual)
  • Speed control of conveyor and sandbelt
  • Easy operation and maintenance

OPTION

  • F2 FILTEALING SYSTEM
  • LOADER & UNLOADER
  • RETURN CONVEYOR
  • FEEDING ROLL CONVEYROR
  • WIDE WIDTH : Max. 850mm
  • Grinding for reducing the thickness after panel plating
  • Ink exclusion on surface of copper after hole plugging process
  • Epoxy exclusion on surface of copper in BVH
  • Surface reveling after TCD coating on build up process
  • Grinding of separate plate for MLB process

  • 판넬 동도금 후 두께편차 및 도금잔사 제거
  • 홀메꿈 인쇄 후 표면의 잉크제거
  • BVH 제조시 프레스 작업 후 스며나온 에폭시 제거
  • BUILD UP 공정에서 에폭시 코팅 후 표면레벨링
  • 다층프레스용 경면판 연마 등 여러분야에 사용

SPECIFICATION

  • Work WidthMax. 610mm / Min. 180mm
  • B/D thickness0.2~4mm
  • Belt sizeW650 x L2160mm
  • Conv.speed1~5M/min
  • Drum dia.160mm
  • EPC unitSensor & Air cylinder
  • Dimensions(2Heads + Return)W1500 x L3750 x H1780
  • Water Consumption30L/min/1HEAD

SPL DRAWING (sheet to sheet Polishing Machine for No.8)
