COIL POLISHINGCOIL POLISHING

COIL POLISHING

This equipment is processing machine Grinding of stainless steel coil face. It is designed easy to adjust the amount of speed coil's feed rate of sand belt rotational speed and grinding loading dose. In addition, as of using water soluble oils, it is safe from the risk of fire and can meet the amount of grinding.

  • Contact Roll : Easy to assemble and disassemble
  • Belt Tracking Sensor : Pneumatic Sensor
  • Oscillation : Smooth operation

CHARACTERISTIC

  • Control SystemAuto program control touch screen
  • Tracking SystemAir cylinder control by air sensor
  • Main motor110kw, 90kw
  • Drum diaInner Dia. 610mm Out Dia. 900~1,200mm
  • ApplicationStainless Steel, Mild Steel, etc.

SPECIFICATION

  • Working width600mm ~ 1,300mm
  • Working Thickness0.25 ~ 8.0mm ±10%
  • Working Speed 5 ~ 20 mpm
  • Surface ConditionCold Rolled

COIL POLISHING

CHARACTERISTIC

  • Washing SystemElectric Clutch Type
  • Washing RollerØ 200 x 1,500mm Non-woven Fabric Roll
  • Main Motor2.2Kw Geared Motor
  • DryerAir Knife Up-Down & Ring Blower Type Heater
  • ▨ Washing & Drying System

  • ▨ Pinching Unit

  • ▨ Welding Machine

  • ▨ Recoiler Machine
